Details
- •Circuit breakers and fuses
- •Miniature circuit breaker (MCB) with auxiliary device
- •1 KOM
- •ABB
Technical specifications
Built-in depth69mm
Frequency50Hz
Voltage typeAC
Control voltage type auxiliary equipmentAC
Over voltage category3
Width in number of modular spacings2
Construction size (according to DIN 43880)2
Rated voltage230V
Rated short-circuit breaking capacity according to IEC 60947-210kA
Rated short-circuit breaking capacity according to EN 610096kA
Concurrently switching neutral conductorYes
Rated voltage auxiliary device230V
Rated switch current auxiliary device-A
Degree of protection (IP)IP2X
Current limiting class4
Pollution degree2
Additional equipment attached at deliveryFire protection switch
Rated current6A
Release characteristicB
Number of poles2
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CSA255901R9065 | S-ARC1 B6
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB) with auxiliary device
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Built-in depth
69mm
Frequency
50Hz
Voltage type
AC
Control voltage type auxiliary equipment
AC
Over voltage category
3
Width in number of modular spacings
2
Construction size (according to DIN 43880)
2
Rated voltage
230V
Rated short-circuit breaking capacity according to IEC 60947-2
10kA
Rated short-circuit breaking capacity according to EN 61009
6kA
Concurrently switching neutral conductor
Rated voltage auxiliary device
230V
Rated switch current auxiliary device
-A
Degree of protection (IP)
IP2X
Current limiting class
4
Pollution degree
2
Additional equipment attached at delivery
Fire protection switch
Rated current
6A
Release characteristic
B
Number of poles
2
