Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Rated control supply voltage Us at AC 50HZ92 - undefinedV
Type of motor starterReversing starter
With short-circuit releaseNo
Rated operation current at AC-3, 400 V9A
Rated operation current Ie9A
Rated control supply voltage Us at AC 60HZ92 - undefinedV
Type of electrical connection of main circuitScrew connection
Voltage type for actuatingAC
Release classCLASS 10
Number of auxiliary contacts as normally closed contact1
External reset possibleYes
Suitable for emergency stopYes
Number of auxiliary contacts as normally open contact1
Number of command positions1
Temperature compensated overload protectionNo
Rail mounting possibleYes
Overload release current setting1.5 - 9A
Type of electrical connection for auxiliary- and control current circuitScrew connection
Degree of protection (IP)IP20
Width22.5mm
Depth114mm
Height107mm
