Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Rated operation current at AC-3, 400 V2.4A
Type of motor starterReversing starter
Rated operation current Ie2.4A
Rated control supply voltage Us at DC19.2 - undefinedV
Number of auxiliary contacts as normally open contact1
Voltage type for actuatingDC
With short-circuit releaseNo
Overload release current setting0.18 - 2.4A
Number of auxiliary contacts as normally closed contact1
Rail mounting possibleYes
Type of electrical connection of main circuitScrew connection
Release classCLASS 10
External reset possibleYes
Temperature compensated overload protectionNo
Type of electrical connection for auxiliary- and control current circuitScrew connection
Degree of protection (IP)IP20
Width22.5mm
Number of command positions1
Depth114mm
Height107mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2297109 | ELR W3- 24DC/500AC- 2I-BR
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/motor starter combination
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Rated operation current at AC-3, 400 V
2.4A
Type of motor starter
Reversing starter
Rated operation current Ie
2.4A
Rated control supply voltage Us at DC
19.2 .. undefinedV
Number of auxiliary contacts as normally open contact
1
Voltage type for actuating
DC
With short-circuit release
Overload release current setting
0.18 .. 2.4A
Number of auxiliary contacts as normally closed contact
1
Rail mounting possible
Type of electrical connection of main circuit
Screw connection
Release class
CLASS 10
External reset possible
Temperature compensated overload protection
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Degree of protection (IP)
IP20
Width
22.5mm
Number of command positions
1
Depth
114mm
Height
107mm
