Details
- •Terminal blocks
- •Component terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Connectable conductor cross section fine-strand without cable end sleeve0.2 - 4mm²
Connectable conductor cross section multi-wired0.2 - 1.5mm²
Connectable conductor cross section solid-core0.2 - 4mm²
Rated voltage500V
Rated current In0.5A
Type of electrical connection 1Screw connection
Internally connected stagesNo
Number of clamp positions per level2
Material insulation bodyOther
Type of electrical connection 2Screw connection
Mounting methodDIN rail (top hat rail) 35 mm
Number of levels2
Height56mm
Width6.2mm
Depth62mm
Inflammability class of insulation material according to with UL94V0
Closing plate requiredYes
Connectable conductor cross section fine-strand with cable end sleeve0.25 - 0.25mm²
ColourGrey
