Details
- •Terminal blocks
- •Component terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Connectable conductor cross section multi-wired0.2 - 1.5mm²
Number of clamp positions per level2
Type of electrical connection 2Screw connection
Connectable conductor cross section solid-core0.2 - 4mm²
Connectable conductor cross section fine-strand without cable end sleeve0.2 - 4mm²
Connectable conductor cross section fine-strand with cable end sleeve0.25 - 0.25mm²
Rated current In32A
Rated voltage24V
Material insulation bodyOther
Width6.2mm
Type of electrical connection 1Screw connection
Inflammability class of insulation material according to with UL94V0
Number of levels2
Depth62mm
Internally connected stagesNo
Closing plate requiredYes
Height56mm
Mounting methodDIN rail (top hat rail) 35 mm
ColourGrey
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2791320 | UKK 5-LA 24 RD/U-O
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Terminal blocks
- Component terminal block
- 50 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Connectable conductor cross section multi-wired
0.2 .. 1.5mm²
Number of clamp positions per level
2
Type of electrical connection 2
Screw connection
Connectable conductor cross section solid-core
0.2 .. 4mm²
Connectable conductor cross section fine-strand without cable end sleeve
0.2 .. 4mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.25 .. 0.25mm²
Rated current In
32A
Rated voltage
24V
Material insulation body
Other
Width
6.2mm
Type of electrical connection 1
Screw connection
Inflammability class of insulation material according to with UL94
V0
Number of levels
2
Depth
62mm
Internally connected stages
Closing plate required
Height
56mm
Mounting method
DIN rail (top hat rail) 35 mm
Colour
Grey
