Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of channels1
Number of inputs, according to NAMUR1
Rated supply voltage at DC19.2 - 30V
Number of inputs, potential-free1
Switching current0.05A
Number of output circuits relays change-over contact0
Type of power supplyOther
Number of output circuits relays normally open contact0
Number of output circuits transistor npn0
Number of output circuits transistor potential-free2
Number of output circuits transistor antivalent0
Switching voltage30V
Number of output circuits transistor pnp2
Number of output circuits opto-coupler0
Galvanic separation between input and outputYes
Malfunction message outputNo
Inherently safe according to EN 60947-5-6 NAMURNo
Galvanic separation between inputsNo
Suitable for safety functionsYes
Galvanic separation between supply voltage and all other current circuitsYes
Height112.5mm
Galvanic separation between output to outputYes
Construction type of deviceBuilt-in device
Type of electric connectionScrew connection
Width12.5mm
Operating temperature-40 - 70°C
Performance level according to EN ISO 13849-1None
Power consumption0.8W
Mounting methodOther
Degree of protection (IP)IP20
Depth113.7mm
