Details
- •Sensors for automation technology
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Switching voltage250V
Number of inputs, potential-free1
Switching power500VA
Number of channels1
Number of output circuits relays normally open contact1
Type of power supplyOther
Number of output circuits transistor npn0
Rated supply voltage at DC19.2 - 30V
Number of output circuits transistor potential-free0
Number of inputs, according to NAMUR1
Number of output circuits transistor pnp0
Number of output circuits opto-coupler0
Galvanic separation between inputsNo
Malfunction message outputNo
Number of output circuits transistor antivalent0
Width12.5mm
Performance level according to EN ISO 13849-1None
Power consumption1W
Construction type of deviceBuilt-in device
Height112.5mm
Depth113.7mm
Mounting methodOther
Type of electric connectionScrew connection
Degree of protection (IP)IP20
Operating temperature-40 - 60°C
Galvanic separation between output to outputNo
Suitable for safety functionsYes
Number of output circuits relays change-over contact1
Inherently safe according to EN 60947-5-6 NAMURYes
Galvanic separation between input and outputYes
Galvanic separation between supply voltage and all other current circuitsYes
