Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Switching power500VA
Rated supply voltage at DC19.2 - 30V
Number of channels1
Switching voltage250V
Number of inputs, according to NAMUR1
Number of output circuits transistor npn0
Malfunction message outputNo
Number of output circuits relays change-over contact0
Galvanic separation between inputsNo
Galvanic separation between input and outputYes
Number of output circuits transistor pnp0
Number of output circuits opto-coupler0
Number of output circuits relays normally open contact2
Number of output circuits transistor antivalent0
Number of output circuits transistor potential-free0
Inherently safe according to EN 60947-5-6 NAMURYes
Type of power supplyOther
Number of inputs, potential-free1
Suitable for safety functionsYes
Galvanic separation between supply voltage and all other current circuitsYes
Galvanic separation between output to outputYes
Performance level according to EN ISO 13849-1None
Type of electric connectionScrew connection
Depth113.7mm
Degree of protection (IP)IP20
Mounting methodOther
Width12.5mm
Height112.5mm
Operating temperature-40 - 60°C
Power consumption1W
Construction type of deviceBuilt-in device
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2865450 | MACX MCR-EX-SL-NAM-2RO
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Switching power
500VA
Rated supply voltage at DC
19.2 .. 30V
Number of channels
1
Switching voltage
250V
Number of inputs, according to NAMUR
1
Number of output circuits transistor npn
0
Malfunction message output
Number of output circuits relays change-over contact
0
Galvanic separation between inputs
Galvanic separation between input and output
Number of output circuits transistor pnp
0
Number of output circuits opto-coupler
0
Number of output circuits relays normally open contact
2
Number of output circuits transistor antivalent
0
Number of output circuits transistor potential-free
0
Inherently safe according to EN 60947-5-6 NAMUR
Type of power supply
Other
Number of inputs, potential-free
1
Suitable for safety functions
Galvanic separation between supply voltage and all other current circuits
Galvanic separation between output to output
Performance level according to EN ISO 13849-1
None
Type of electric connection
Screw connection
Depth
113.7mm
Degree of protection (IP)
IP20
Mounting method
Other
Width
12.5mm
Height
112.5mm
Operating temperature
-40 .. 60°C
Power consumption
1W
Construction type of device
Built-in device
