Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of inputs, according to NAMUR1
Type of power supplyOther
Number of channels1
Number of output circuits relays normally open contact0
Switching current0.05A
Number of output circuits relays change-over contact0
Switching voltage30V
Rated supply voltage at DC19.2 - 30V
Number of inputs, potential-free1
Inherently safe according to EN 60947-5-6 NAMURYes
Number of output circuits opto-coupler0
Number of output circuits transistor potential-free2
Galvanic separation between input and outputYes
Malfunction message outputNo
Galvanic separation between inputsNo
Number of output circuits transistor antivalent0
Number of output circuits transistor npn0
Number of output circuits transistor pnp2
Operating temperature-40 - 70°C
Performance level according to EN ISO 13849-1None
Galvanic separation between output to outputYes
Type of electric connectionScrew connection
Height112.5mm
Suitable for safety functionsYes
Width12.5mm
Galvanic separation between supply voltage and all other current circuitsYes
Depth113.7mm
Construction type of deviceBuilt-in device
Power consumption0.8W
Mounting methodOther
Degree of protection (IP)IP20
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2865463 | MACX MCR-EX-SL-NAM-2T
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Number of inputs, according to NAMUR
1
Type of power supply
Other
Number of channels
1
Number of output circuits relays normally open contact
0
Switching current
0.05A
Number of output circuits relays change-over contact
0
Switching voltage
30V
Rated supply voltage at DC
19.2 .. 30V
Number of inputs, potential-free
1
Inherently safe according to EN 60947-5-6 NAMUR
Number of output circuits opto-coupler
0
Number of output circuits transistor potential-free
2
Galvanic separation between input and output
Malfunction message output
Galvanic separation between inputs
Number of output circuits transistor antivalent
0
Number of output circuits transistor npn
0
Number of output circuits transistor pnp
2
Operating temperature
-40 .. 70°C
Performance level according to EN ISO 13849-1
None
Galvanic separation between output to output
Type of electric connection
Screw connection
Height
112.5mm
Suitable for safety functions
Width
12.5mm
Galvanic separation between supply voltage and all other current circuits
Depth
113.7mm
Construction type of device
Built-in device
Power consumption
0.8W
Mounting method
Other
Degree of protection (IP)
IP20
