Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Rated supply voltage at DC19.2 - 30V
Switching voltage30V
Number of inputs, according to NAMUR2
Number of channels2
Switching current0.05A
Number of output circuits transistor antivalent0
Number of output circuits transistor potential-free1
Number of output circuits relays normally open contact0
Malfunction message outputNo
Number of output circuits transistor pnp1
Number of inputs, potential-free2
Number of output circuits relays change-over contact0
Number of output circuits opto-coupler0
Number of output circuits transistor npn0
Inherently safe according to EN 60947-5-6 NAMURYes
Galvanic separation between inputsNo
Galvanic separation between input and outputYes
Performance level according to EN ISO 13849-1None
Galvanic separation between supply voltage and all other current circuitsYes
Galvanic separation between output to outputYes
Height112.5mm
Width12.5mm
Operating temperature-40 - 70°C
Suitable for safety functionsYes
Type of electric connectionScrew connection
Degree of protection (IP)IP20
Power consumption0.8W
Mounting methodOther
Depth113.7mm
Construction type of deviceBuilt-in device
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2865489 | MACX MCR-EX-SL-2NAM-T
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of power supply
Other
Rated supply voltage at DC
19.2 .. 30V
Switching voltage
30V
Number of inputs, according to NAMUR
2
Number of channels
2
Switching current
0.05A
Number of output circuits transistor antivalent
0
Number of output circuits transistor potential-free
1
Number of output circuits relays normally open contact
0
Malfunction message output
Number of output circuits transistor pnp
1
Number of inputs, potential-free
2
Number of output circuits relays change-over contact
0
Number of output circuits opto-coupler
0
Number of output circuits transistor npn
0
Inherently safe according to EN 60947-5-6 NAMUR
Galvanic separation between inputs
Galvanic separation between input and output
Performance level according to EN ISO 13849-1
None
Galvanic separation between supply voltage and all other current circuits
Galvanic separation between output to output
Height
112.5mm
Width
12.5mm
Operating temperature
-40 .. 70°C
Suitable for safety functions
Type of electric connection
Screw connection
Degree of protection (IP)
IP20
Power consumption
0.8W
Mounting method
Other
Depth
113.7mm
Construction type of device
Built-in device
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
