Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Switching voltage8.2V
Number of channels1
Type of power supplyOther
Number of inputs, according to NAMUR1
Number of inputs, potential-free1
Number of output circuits transistor potential-free1
Rated supply voltage at DC9.6 - 30V
Number of output circuits relays change-over contact0
Number of output circuits opto-coupler0
Number of output circuits transistor npn0
Malfunction message outputNo
Number of output circuits transistor antivalent0
Galvanic separation between input and outputYes
Galvanic separation between inputsNo
Galvanic separation between output to outputNo
Inherently safe according to EN 60947-5-6 NAMURYes
Number of output circuits transistor pnp1
Number of output circuits relays normally open contact0
Suitable for safety functionsYes
Construction type of deviceBuilt-in device
Power consumption0.6W
Galvanic separation between supply voltage and all other current circuitsYes
Operating temperature-40 - 70°C
Degree of protection (IP)IP20
Width12.5mm
Mounting methodOther
Height112.5mm
Type of electric connectionScrew connection
Depth113.7mm
Performance level according to EN ISO 13849-1None
