Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Type of motor starterReversing starter
With short-circuit releaseNo
Rated control supply voltage Us at AC 60HZ85 - undefinedV
Voltage type for actuatingAC
Number of auxiliary contacts as normally closed contact1
Number of auxiliary contacts as normally open contact1
Type of electrical connection for auxiliary- and control current circuitScrew connection
Release classCLASS 10
Type of electrical connection of main circuitScrew connection
Rated operation current at AC-3, 400 V2.4A
External reset possibleYes
Rail mounting possibleYes
Number of command positions1
Suitable for emergency stopYes
Temperature compensated overload protectionNo
Rated control supply voltage Us at AC 50HZ85 - undefinedV
Height107mm
Width22.5mm
Depth114mm
Rated operation current Ie2.4A
Overload release current setting0.18 - 2.4A
Degree of protection (IP)IP20
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2900420 | ELR H5-IES-SC-230AC/500AC-2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/motor starter combination
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of motor starter
Reversing starter
With short-circuit release
Rated control supply voltage Us at AC 60HZ
85 .. undefinedV
Voltage type for actuating
AC
Number of auxiliary contacts as normally closed contact
1
Number of auxiliary contacts as normally open contact
1
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Release class
CLASS 10
Type of electrical connection of main circuit
Screw connection
Rated operation current at AC-3, 400 V
2.4A
External reset possible
Rail mounting possible
Number of command positions
1
Suitable for emergency stop
Temperature compensated overload protection
Rated control supply voltage Us at AC 50HZ
85 .. undefinedV
Height
107mm
Width
22.5mm
Depth
114mm
Rated operation current Ie
2.4A
Overload release current setting
0.18 .. 2.4A
Degree of protection (IP)
IP20
