Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Voltage type for actuatingDC
Type of motor starterDirect online starter (DOL)
Rated operation current Ie9A
Rated control supply voltage Us at DC19.2 - undefinedV
Rated operation current at AC-3, 400 V9A
With short-circuit releaseNo
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Type of electrical connection of main circuitScrew connection
Overload release current setting0 - 9A
Temperature compensated overload protectionNo
Type of electrical connection for auxiliary- and control current circuitScrew connection
Degree of protection (IP)IP20
Number of command positions0
Rail mounting possibleYes
External reset possibleYes
Width22.5mm
Height107mm
Depth114mm
