Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Rated control supply voltage Us at DC19.2 - undefinedV
Overload release current setting0.18 - 2.4A
Number of auxiliary contacts as normally open contact1
Rated operation current at AC-3, 400 V2.4A
Voltage type for actuatingDC
Rated operation current Ie2.4A
Type of motor starterDirect online starter (DOL)
Number of auxiliary contacts as normally closed contact1
Temperature compensated overload protectionNo
Type of electrical connection for auxiliary- and control current circuitScrew connection
Release classCLASS 10
Rail mounting possibleYes
Type of electrical connection of main circuitScrew connection
Number of command positions1
Width22.5mm
Degree of protection (IP)IP20
External reset possibleYes
With short-circuit releaseNo
Height107mm
Depth114mm
