Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Type of motor starterDirect online starter (DOL)
Rated control supply voltage Us at DC19.2 - undefinedV
Temperature compensated overload protectionNo
Overload release current setting1.5 - 9A
Voltage type for actuatingDC
Rated operation current at AC-3, 400 V9A
Rated operation current Ie9A
Number of auxiliary contacts as normally closed contact1
With short-circuit releaseNo
Number of auxiliary contacts as normally open contact1
Release classCLASS 10
Type of electrical connection for auxiliary- and control current circuitScrew connection
Number of command positions1
Type of electrical connection of main circuitScrew connection
Rail mounting possibleYes
Width22.5mm
Degree of protection (IP)IP20
External reset possibleYes
Height107mm
Depth114mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2900545 | ELR H3-I-SC- 24DC/500AC-9
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/motor starter combination
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of motor starter
Direct online starter (DOL)
Rated control supply voltage Us at DC
19.2 .. undefinedV
Temperature compensated overload protection
Overload release current setting
1.5 .. 9A
Voltage type for actuating
DC
Rated operation current at AC-3, 400 V
9A
Rated operation current Ie
9A
Number of auxiliary contacts as normally closed contact
1
With short-circuit release
Number of auxiliary contacts as normally open contact
1
Release class
CLASS 10
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Number of command positions
1
Type of electrical connection of main circuit
Screw connection
Rail mounting possible
Width
22.5mm
Degree of protection (IP)
IP20
External reset possible
Height
107mm
Depth
114mm
