Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Rated operation current at AC-3, 400 V9A
Type of motor starterReversing starter
With short-circuit releaseNo
Type of electrical connection of main circuitScrew connection
Rated control supply voltage Us at DC19.2 - undefinedV
Number of auxiliary contacts as normally open contact1
Voltage type for actuatingDC
Rated operation current Ie9A
Release classCLASS 10
Temperature compensated overload protectionNo
Type of electrical connection for auxiliary- and control current circuitScrew connection
Rail mounting possibleYes
External reset possibleYes
Number of auxiliary contacts as normally closed contact1
Number of command positions1
Degree of protection (IP)IP20
Overload release current setting1.5 - 9A
Suitable for emergency stopYes
Width22.5mm
Depth114mm
Height107mm
