Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
With short-circuit releaseNo
Voltage type for actuatingDC
Number of auxiliary contacts as normally open contact1
Rated operation current Ie0.6A
Rated control supply voltage Us at DC19.2 - undefinedV
Overload release current setting0.075 - 0.6A
Type of motor starterReversing starter
Rated operation current at AC-3, 400 V0.6A
Number of auxiliary contacts as normally closed contact1
Type of electrical connection of main circuitScrew connection
Type of electrical connection for auxiliary- and control current circuitScrew connection
Release classCLASS 10
Number of command positions1
Rail mounting possibleYes
External reset possibleYes
Suitable for emergency stopYes
Degree of protection (IP)IP20
Temperature compensated overload protectionNo
Width22.5mm
Height107mm
Depth114mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2900582 | ELR H5-IES-SC- 24DC/500AC-0,6
