Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Rated control supply voltage Us at DC19.2 - undefinedV
With short-circuit releaseNo
Type of motor starterReversing starter
Voltage type for actuatingDC
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Rated operation current at AC-3, 400 V2.4A
Temperature compensated overload protectionNo
Type of electrical connection of main circuitScrew connection
Release classCLASS 10
Rail mounting possibleYes
Number of command positions1
Type of electrical connection for auxiliary- and control current circuitScrew connection
Width22.5mm
External reset possibleYes
Height107mm
Depth114mm
Rated operation current Ie2.4A
Overload release current setting0.18 - 2.4A
Degree of protection (IP)IP20
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2901063 | ELR H5-I-SC- 24DC/500AC-2-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Motor starter/motor starter combination
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Rated control supply voltage Us at DC
19.2 .. undefinedV
With short-circuit release
Type of motor starter
Reversing starter
Voltage type for actuating
DC
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Rated operation current at AC-3, 400 V
2.4A
Temperature compensated overload protection
Type of electrical connection of main circuit
Screw connection
Release class
CLASS 10
Rail mounting possible
Number of command positions
1
Type of electrical connection for auxiliary- and control current circuit
Screw connection
Width
22.5mm
External reset possible
Height
107mm
Depth
114mm
Rated operation current Ie
2.4A
Overload release current setting
0.18 .. 2.4A
Degree of protection (IP)
IP20
