Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Rated supply voltage at DC9.6 - 30V
Number of output circuits transistor potential-free2
Number of output circuits relays change-over contact0
Switching voltage30V
Number of output circuits relays normally open contact2
Number of output circuits transistor antivalent0
Number of channels1
Number of output circuits transistor npn0
Number of output circuits transistor pnp2
Number of inputs, according to NAMUR1
Number of output circuits opto-coupler0
Inherently safe according to EN 60947-5-6 NAMURNo
Malfunction message outputNo
Galvanic separation between input and outputYes
Galvanic separation between output to outputYes
Galvanic separation between inputsNo
Number of inputs, potential-free1
Suitable for safety functionsNo
Galvanic separation between supply voltage and all other current circuitsYes
Construction type of deviceBuilt-in device
Height109.81mm
Power consumption0.45W
Degree of protection (IP)IP20
Width6.2mm
Operating temperature-40 - 70°C
Performance level according to EN ISO 13849-1None
Depth119.2mm
Type of electric connectionOther
Mounting methodOther
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2902005 | MINI MCR-2-NAM-2RO-PT
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of power supply
Other
Rated supply voltage at DC
9.6 .. 30V
Number of output circuits transistor potential-free
2
Number of output circuits relays change-over contact
0
Switching voltage
30V
Number of output circuits relays normally open contact
2
Number of output circuits transistor antivalent
0
Number of channels
1
Number of output circuits transistor npn
0
Number of output circuits transistor pnp
2
Number of inputs, according to NAMUR
1
Number of output circuits opto-coupler
0
Inherently safe according to EN 60947-5-6 NAMUR
Malfunction message output
Galvanic separation between input and output
Galvanic separation between output to output
Galvanic separation between inputs
Number of inputs, potential-free
1
Suitable for safety functions
Galvanic separation between supply voltage and all other current circuits
Construction type of device
Built-in device
Height
109.81mm
Power consumption
0.45W
Degree of protection (IP)
IP20
Width
6.2mm
Operating temperature
-40 .. 70°C
Performance level according to EN ISO 13849-1
None
Depth
119.2mm
Type of electric connection
Other
Mounting method
Other
Related products
