Details
- •Low-voltage industrial components
- •Motor starter/motor starter combination
- •1 KOM
- •PHOENIX
Technical specifications
Number of auxiliary contacts as normally closed contact1
Rated operation current Ie2.4A
Number of auxiliary contacts as normally open contact1
Type of motor starterDirect online starter (DOL)
Rated control supply voltage Us at DC19.2 - undefinedV
Number of command positions1
Rail mounting possibleYes
External reset possibleYes
With short-circuit releaseNo
Width22.5mm
Overload release current setting0.18 - 2.4A
Release classCLASS 10
Suitable for emergency stopYes
Type of electrical connection for auxiliary- and control current circuitSpring clamp connection
Temperature compensated overload protectionNo
Rated operation current at AC-3, 400 V2.4A
Type of electrical connection of main circuitSpring clamp connection
Degree of protection (IP)IP20
Depth114mm
Height107.5mm
