Details
- •Sensors
- •Isolation amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of input ranges -60 mV ... +60 mV0
Type of power supplyOther
Number of input ranges -5 V ... +5 V0
Number of input ranges -500 mV ... +500 mV0
Number of input ranges -2 V ... +2 V0
Number of input ranges -100 mV ... +100 mV0
Number of input ranges 0 mV ... 200 mV0
Number of input ranges -1 V ... +1 V0
Number of input ranges -300 mV ... +300 mV0
Rated supply voltage at DC9.6 - 30V
Number of input ranges 0 mV ... 60 mV0
Number of input ranges -2.5 V ... +2.5 V0
Number of input ranges -10 V ... +10 V0
Number of input ranges -20 V ... +20 V0
Number of input ranges 0 mV ... 500 mV0
Number of input ranges 0 V ... 1 V0
Number of input ranges 0 mV ... 300 mV0
Number of input ranges 0 mV ... 100 mV0
Number of input ranges 0 V ... 5 V1
Number of input ranges 0 V ... 2.5 V0
Number of input ranges 0 V ... 20 V0
Number of input ranges 0 V ... 2 V0
Number of input ranges 1 V ... 5 V1
Number of input ranges 0 V ... 24 V0
Number of input ranges 5 V ... 1 V0
Number of input ranges 2 V ... 10 V1
Number of input ranges 0 V ... 30 V0
Number of input ranges 10 V ... 0 V0
Number of input ranges 5 V ... 0 V0
Number of input ranges +5 V ... -5 V0
Number of input ranges 10 V ... 2 V0
Number of input ranges 0 mA ... 5 mA0
Number of input ranges +10 V ... -10 V0
Number of input ranges 0 mA ... 10 mA1
Number of input ranges 0 mA ... 20 mA1
Number of input ranges 0 V ... 10 V1
Number of input ranges 4 mA ... 20 mA1
Number of input ranges -10 mA ... +10 mA0
Number of input ranges -5 mA ... +5 mA0
Number of output ranges -2 V ... +2 V0
Number of input ranges -20 mA ... +20 mA0
Number of input ranges 20 mA ... 0 mA1
Number of input ranges 20 mA ... 4 mA0
Number of output ranges -300 mV ... +300 mV0
Number of output ranges -100 mV ... +100 mV0
Number of output ranges -500 mV ... +500 mV0
Number of output ranges -60 mV ... +60 mV0
Number of output ranges -1 V ... +1 V0
Number of output ranges -20 V ... +20 V0
Number of output ranges -2.5 V ... +2.5 V0
Number of output ranges -5 V ... +5 V0
Number of output ranges 0 mV ... 300 mV0
Number of output ranges 0 mV ... 200 mV0
Number of output ranges 0 mV ... 60 mV0
Number of output ranges 0 mV ... 100 mV0
Number of output ranges -10 V ... +10 V0
Number of output ranges 0 V ... 2.5 V0
Number of output ranges 0 V ... 1 V0
Number of output ranges 0 mV ... 500 mV0
Number of output ranges 0 V ... 2 V0
Number of output ranges 0 V ... 5 V1
Number of output ranges 0 V ... 30 V0
Number of output ranges 0 V ... 24 V0
Number of output ranges 1 V ... 5 V1
Number of output ranges 0 V ... 10 V1
Number of output ranges 0 mA ... 5 mA0
Number of output ranges 2 V ... 10 V1
Number of output ranges +10 V ... -10 V0
Number of output ranges +5 V ... -5 V0
Number of output ranges 0 mA ... 10 mA1
Number of output ranges 10 V ... 2 V0
Number of output ranges 10 V ... 0 V0
Number of output ranges 5 V ... 0 V0
Number of output ranges 0 V ... 20 V0
Number of output ranges 5 V ... 1 V0
Number of output ranges 4 mA ... 20 mA1
Number of output ranges -10 mA ... +10 mA0
Number of output ranges -20 mA ... +20 mA0
Number of output ranges -5 mA ... +5 mA0
Number of output ranges 0 mA ... 20 mA1
Number of output ranges 20 mA ... 0 mA1
Number of channels2
Depth119.2mm
Inherently safe according to EN 60947-5-6 NAMURNo
Malfunction message outputNo
Width6.2mm
SIL according to IEC 61508None
Number of output ranges 20 mA ... 4 mA0
Height109.81mm
Load600 - 10000Ohm
Galvanic separation between inputsNo
Type of electric connectionOther
Operating temperature-40 - 70°C
Construction type of deviceBuilt-in device
Temperature drift0.01%/K
Mounting methodSnap mounting support rail
Power consumption1.5W
Degree of protection (IP)IP20
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2905028 | MINI MCR-2-UNI-UI-2UI-PT
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Isolation amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Number of input ranges -60 mV ... +60 mV
0
Type of power supply
Other
Number of input ranges -5 V ... +5 V
0
Number of input ranges -500 mV ... +500 mV
0
Number of input ranges -2 V ... +2 V
0
Number of input ranges -100 mV ... +100 mV
0
Number of input ranges 0 mV ... 200 mV
0
Number of input ranges -1 V ... +1 V
0
Number of input ranges -300 mV ... +300 mV
0
Rated supply voltage at DC
9.6 .. 30V
Number of input ranges 0 mV ... 60 mV
0
Number of input ranges -2.5 V ... +2.5 V
0
Number of input ranges -10 V ... +10 V
0
Number of input ranges -20 V ... +20 V
0
Number of input ranges 0 mV ... 500 mV
0
Number of input ranges 0 V ... 1 V
0
Number of input ranges 0 mV ... 300 mV
0
Number of input ranges 0 mV ... 100 mV
0
Number of input ranges 0 V ... 5 V
1
Number of input ranges 0 V ... 2.5 V
0
Number of input ranges 0 V ... 20 V
0
Number of input ranges 0 V ... 2 V
0
Number of input ranges 1 V ... 5 V
1
Number of input ranges 0 V ... 24 V
0
Number of input ranges 5 V ... 1 V
0
Number of input ranges 2 V ... 10 V
1
Number of input ranges 0 V ... 30 V
0
Number of input ranges 10 V ... 0 V
0
Number of input ranges 5 V ... 0 V
0
Number of input ranges +5 V ... -5 V
0
Number of input ranges 10 V ... 2 V
0
Number of input ranges 0 mA ... 5 mA
0
Number of input ranges +10 V ... -10 V
0
Number of input ranges 0 mA ... 10 mA
1
Number of input ranges 0 mA ... 20 mA
1
Number of input ranges 0 V ... 10 V
1
Number of input ranges 4 mA ... 20 mA
1
Number of input ranges -10 mA ... +10 mA
0
Number of input ranges -5 mA ... +5 mA
0
Number of output ranges -2 V ... +2 V
0
Number of input ranges -20 mA ... +20 mA
0
Number of input ranges 20 mA ... 0 mA
1
Number of input ranges 20 mA ... 4 mA
0
Number of output ranges -300 mV ... +300 mV
0
Number of output ranges -100 mV ... +100 mV
0
Number of output ranges -500 mV ... +500 mV
0
Number of output ranges -60 mV ... +60 mV
0
Number of output ranges -1 V ... +1 V
0
Number of output ranges -20 V ... +20 V
0
Number of output ranges -2.5 V ... +2.5 V
0
Number of output ranges -5 V ... +5 V
0
Number of output ranges 0 mV ... 300 mV
0
Number of output ranges 0 mV ... 200 mV
0
Number of output ranges 0 mV ... 60 mV
0
Number of output ranges 0 mV ... 100 mV
0
Number of output ranges -10 V ... +10 V
0
Number of output ranges 0 V ... 2.5 V
0
Number of output ranges 0 V ... 1 V
0
Number of output ranges 0 mV ... 500 mV
0
Number of output ranges 0 V ... 2 V
0
Number of output ranges 0 V ... 5 V
1
Number of output ranges 0 V ... 30 V
0
Number of output ranges 0 V ... 24 V
0
Number of output ranges 1 V ... 5 V
1
Number of output ranges 0 V ... 10 V
1
Number of output ranges 0 mA ... 5 mA
0
Number of output ranges 2 V ... 10 V
1
Number of output ranges +10 V ... -10 V
0
Number of output ranges +5 V ... -5 V
0
Number of output ranges 0 mA ... 10 mA
1
Number of output ranges 10 V ... 2 V
0
Number of output ranges 10 V ... 0 V
0
Number of output ranges 5 V ... 0 V
0
Number of output ranges 0 V ... 20 V
0
Number of output ranges 5 V ... 1 V
0
Number of output ranges 4 mA ... 20 mA
1
Number of output ranges -10 mA ... +10 mA
0
Number of output ranges -20 mA ... +20 mA
0
Number of output ranges -5 mA ... +5 mA
0
Number of output ranges 0 mA ... 20 mA
1
Number of output ranges 20 mA ... 0 mA
1
Number of channels
2
Depth
119.2mm
Inherently safe according to EN 60947-5-6 NAMUR
Malfunction message output
Width
6.2mm
SIL according to IEC 61508
None
Number of output ranges 20 mA ... 4 mA
0
Height
109.81mm
Load
600 .. 10000Ohm
Galvanic separation between inputs
Type of electric connection
Other
Operating temperature
-40 .. 70°C
Construction type of device
Built-in device
Temperature drift
0.01%/K
Mounting method
Snap mounting support rail
Power consumption
1.5W
Degree of protection (IP)
IP20
