Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Number of inputs, potential-free1
Rated supply voltage at DC19.2 - 30V
Number of output circuits relays normally open contact1
Switching power500VA
Switching voltage250V
Number of inputs, according to NAMUR1
Number of output circuits transistor potential-free0
Number of output circuits opto-coupler0
Malfunction message outputNo
Number of output circuits transistor antivalent0
Number of output circuits relays change-over contact0
Number of output circuits transistor pnp0
Number of output circuits transistor npn0
Galvanic separation between inputsNo
Inherently safe according to EN 60947-5-6 NAMURYes
Galvanic separation between input and outputYes
Number of channels1
Galvanic separation between output to outputNo
Power consumption1W
Galvanic separation between supply voltage and all other current circuitsYes
Width12.5mm
Performance level according to EN ISO 13849-1None
Operating temperature-40 - 60°C
Height107.9mm
Construction type of deviceBuilt-in device
Depth113.7mm
Mounting methodOther
Degree of protection (IP)IP20
Type of electric connectionOther
Suitable for safety functionsYes
