Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Number of output circuits relays normally open contact0
Switching current0.05A
Switching voltage30V
Number of output circuits transistor pnp2
Number of inputs, potential-free1
Number of output circuits transistor npn0
Inherently safe according to EN 60947-5-6 NAMURYes
Number of output circuits relays change-over contact0
Number of output circuits opto-coupler0
Number of output circuits transistor antivalent0
Malfunction message outputNo
Galvanic separation between inputsNo
Number of output circuits transistor potential-free2
Galvanic separation between input and outputYes
Galvanic separation between output to outputYes
Galvanic separation between supply voltage and all other current circuitsYes
Width12.5mm
Construction type of deviceBuilt-in device
Operating temperature-40 - 70°C
Type of electric connectionOther
Performance level according to EN ISO 13849-1None
Mounting methodOther
Height116mm
Degree of protection (IP)IP20
Depth113.7mm
Power consumption0.8W
Suitable for safety functionsYes
Number of channels1
Number of inputs, according to NAMUR1
Rated supply voltage at DC19.2 - 30V
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924074 | MACX MCR-EX-SL-NAM-2T-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of power supply
Other
Number of output circuits relays normally open contact
0
Switching current
0.05A
Switching voltage
30V
Number of output circuits transistor pnp
2
Number of inputs, potential-free
1
Number of output circuits transistor npn
0
Inherently safe according to EN 60947-5-6 NAMUR
Number of output circuits relays change-over contact
0
Number of output circuits opto-coupler
0
Number of output circuits transistor antivalent
0
Malfunction message output
Galvanic separation between inputs
Number of output circuits transistor potential-free
2
Galvanic separation between input and output
Galvanic separation between output to output
Galvanic separation between supply voltage and all other current circuits
Width
12.5mm
Construction type of device
Built-in device
Operating temperature
-40 .. 70°C
Type of electric connection
Other
Performance level according to EN ISO 13849-1
None
Mounting method
Other
Height
116mm
Degree of protection (IP)
IP20
Depth
113.7mm
Power consumption
0.8W
Suitable for safety functions
Number of channels
1
Number of inputs, according to NAMUR
1
Rated supply voltage at DC
19.2 .. 30V
