Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Number of channels2
Switching power500VA
Number of inputs, potential-free0
Number of output circuits transistor potential-free0
Rated supply voltage at DC19.2 - 30V
Switching voltage250V
Number of output circuits relays change-over contact0
Number of output circuits transistor pnp0
Number of output circuits transistor antivalent0
Malfunction message outputNo
Number of output circuits relays normally open contact2
Number of output circuits opto-coupler0
Number of output circuits transistor npn0
Galvanic separation between inputsNo
Inherently safe according to EN 60947-5-6 NAMURYes
Number of inputs, according to NAMUR2
Galvanic separation between input and outputYes
Suitable for safety functionsYes
Width12.5mm
Galvanic separation between supply voltage and all other current circuitsYes
Galvanic separation between output to outputYes
Depth113.7mm
Construction type of deviceBuilt-in device
Height107.9mm
Type of electric connectionOther
Performance level according to EN ISO 13849-1None
Operating temperature-40 - 60°C
Mounting methodOther
Power consumption1W
Degree of protection (IP)IP20
