Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Type of power supplyOther
Rated supply voltage at AC19.2 - 253V
Number of inputs, according to NAMUR2
Number of inputs, potential-free2
Switching power500VA
Number of output circuits relays normally open contact0
Number of channels2
Number of output circuits transistor potential-free0
Number of output circuits transistor npn0
Number of output circuits relays change-over contact2
Switching voltage250V
Number of output circuits transistor pnp0
Rated supply voltage at DC19.2 - 253V
Inherently safe according to EN 60947-5-6 NAMURYes
Malfunction message outputNo
Galvanic separation between inputsNo
Number of output circuits transistor antivalent0
Number of output circuits opto-coupler0
Galvanic separation between input and outputYes
Galvanic separation between supply voltage and all other current circuitsYes
Performance level according to EN ISO 13849-1None
Suitable for safety functionsYes
Height107.9mm
Construction type of deviceBuilt-in device
Operating temperature-40 - 60°C
Mounting methodOther
Type of electric connectionOther
Degree of protection (IP)IP20
Galvanic separation between output to outputYes
Depth113.7mm
Width17.5mm
Power consumption1.1W
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924249 | MACX MCR-EX-SL-2NAM-R-UP-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of power supply
Other
Rated supply voltage at AC
19.2 .. 253V
Number of inputs, according to NAMUR
2
Number of inputs, potential-free
2
Switching power
500VA
Number of output circuits relays normally open contact
0
Number of channels
2
Number of output circuits transistor potential-free
0
Number of output circuits transistor npn
0
Number of output circuits relays change-over contact
2
Switching voltage
250V
Number of output circuits transistor pnp
0
Rated supply voltage at DC
19.2 .. 253V
Inherently safe according to EN 60947-5-6 NAMUR
Malfunction message output
Galvanic separation between inputs
Number of output circuits transistor antivalent
0
Number of output circuits opto-coupler
0
Galvanic separation between input and output
Galvanic separation between supply voltage and all other current circuits
Performance level according to EN ISO 13849-1
None
Suitable for safety functions
Height
107.9mm
Construction type of device
Built-in device
Operating temperature
-40 .. 60°C
Mounting method
Other
Type of electric connection
Other
Degree of protection (IP)
IP20
Galvanic separation between output to output
Depth
113.7mm
Width
17.5mm
Power consumption
1.1W
