Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Switching power500VA
Number of output circuits relays normally open contact1
Type of power supplyOther
Number of channels1
Number of inputs, according to NAMUR1
Number of inputs, potential-free1
Switching voltage250V
Rated supply voltage at DC19.2 - 30V
Number of output circuits relays change-over contact1
Number of output circuits transistor potential-free0
Number of output circuits transistor pnp0
Malfunction message outputNo
Number of output circuits transistor antivalent0
Inherently safe according to EN 60947-5-6 NAMURNo
Number of output circuits transistor npn0
Galvanic separation between inputsNo
Galvanic separation between input and outputYes
Number of output circuits opto-coupler0
Galvanic separation between output to outputNo
Galvanic separation between supply voltage and all other current circuitsYes
Suitable for safety functionsYes
Performance level according to EN ISO 13849-1None
Operating temperature-40 - 60°C
Height107.9mm
Construction type of deviceBuilt-in device
Type of electric connectionOther
Depth113.7mm
Mounting methodOther
Power consumption0.65W
Degree of protection (IP)IP20
Width12.5mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924252 | MACX MCR-SL-NAM-R-SP
