Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of channels1
Switching voltage250V
Number of output circuits relays change-over contact0
Number of output circuits transistor pnp0
Number of output circuits relays normally open contact2
Number of output circuits transistor potential-free0
Number of inputs, potential-free1
Number of output circuits transistor antivalent0
Switching power500VA
Malfunction message outputNo
Number of output circuits transistor npn0
Number of inputs, according to NAMUR1
Inherently safe according to EN 60947-5-6 NAMURNo
Galvanic separation between input and outputYes
Galvanic separation between inputsNo
Number of output circuits opto-coupler0
Rated supply voltage at DC19.2 - 30V
Type of power supplyOther
Galvanic separation between supply voltage and all other current circuitsYes
Galvanic separation between output to outputYes
Suitable for safety functionsYes
Height107.9mm
Performance level according to EN ISO 13849-1None
Construction type of deviceBuilt-in device
Width12.5mm
Type of electric connectionOther
Depth113.7mm
Operating temperature-40 - 60°C
Degree of protection (IP)IP20
Mounting methodOther
Power consumption0.95W
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924265 | MACX MCR-SL-NAM-2RO-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Number of channels
1
Switching voltage
250V
Number of output circuits relays change-over contact
0
Number of output circuits transistor pnp
0
Number of output circuits relays normally open contact
2
Number of output circuits transistor potential-free
0
Number of inputs, potential-free
1
Number of output circuits transistor antivalent
0
Switching power
500VA
Malfunction message output
Number of output circuits transistor npn
0
Number of inputs, according to NAMUR
1
Inherently safe according to EN 60947-5-6 NAMUR
Galvanic separation between input and output
Galvanic separation between inputs
Number of output circuits opto-coupler
0
Rated supply voltage at DC
19.2 .. 30V
Type of power supply
Other
Galvanic separation between supply voltage and all other current circuits
Galvanic separation between output to output
Suitable for safety functions
Height
107.9mm
Performance level according to EN ISO 13849-1
None
Construction type of device
Built-in device
Width
12.5mm
Type of electric connection
Other
Depth
113.7mm
Operating temperature
-40 .. 60°C
Degree of protection (IP)
IP20
Mounting method
Other
Power consumption
0.95W
