Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Rated supply voltage at DC19.2 - 30V
Switching current0.05A
Number of inputs, potential-free1
Type of power supplyOther
Number of output circuits relays normally open contact0
Switching voltage30V
Number of output circuits relays change-over contact0
Number of output circuits transistor potential-free2
Number of output circuits transistor pnp2
Number of channels1
Number of output circuits opto-coupler0
Number of output circuits transistor npn0
Malfunction message outputNo
Number of inputs, according to NAMUR1
Number of output circuits transistor antivalent0
Inherently safe according to EN 60947-5-6 NAMURNo
Galvanic separation between inputsNo
Galvanic separation between input and outputYes
Galvanic separation between output to outputYes
Performance level according to EN ISO 13849-1None
Power consumption0.8W
Construction type of deviceBuilt-in device
Width12.5mm
Suitable for safety functionsYes
Mounting methodOther
Type of electric connectionOther
Operating temperature-40 - 70°C
Depth113.7mm
Degree of protection (IP)IP20
Galvanic separation between supply voltage and all other current circuitsYes
Height116mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924278 | MACX MCR-SL-NAM-2T-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Rated supply voltage at DC
19.2 .. 30V
Switching current
0.05A
Number of inputs, potential-free
1
Type of power supply
Other
Number of output circuits relays normally open contact
0
Switching voltage
30V
Number of output circuits relays change-over contact
0
Number of output circuits transistor potential-free
2
Number of output circuits transistor pnp
2
Number of channels
1
Number of output circuits opto-coupler
0
Number of output circuits transistor npn
0
Malfunction message output
Number of inputs, according to NAMUR
1
Number of output circuits transistor antivalent
0
Inherently safe according to EN 60947-5-6 NAMUR
Galvanic separation between inputs
Galvanic separation between input and output
Galvanic separation between output to output
Performance level according to EN ISO 13849-1
None
Power consumption
0.8W
Construction type of device
Built-in device
Width
12.5mm
Suitable for safety functions
Mounting method
Other
Type of electric connection
Other
Operating temperature
-40 .. 70°C
Depth
113.7mm
Degree of protection (IP)
IP20
Galvanic separation between supply voltage and all other current circuits
Height
116mm
