Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of inputs, potential-free2
Switching current0.05A
Number of inputs, according to NAMUR2
Number of output circuits transistor potential-free1
Switching voltage30V
Number of output circuits relays normally open contact0
Number of output circuits relays change-over contact0
Number of output circuits opto-coupler0
Type of power supplyOther
Malfunction message outputNo
Inherently safe according to EN 60947-5-6 NAMURNo
Number of channels2
Galvanic separation between inputsNo
Number of output circuits transistor pnp1
Rated supply voltage at DC19.2 - 30V
Number of output circuits transistor antivalent0
Number of output circuits transistor npn0
Galvanic separation between input and outputYes
Height116mm
Type of electric connectionOther
Operating temperature-40 - 70°C
Galvanic separation between supply voltage and all other current circuitsYes
Performance level according to EN ISO 13849-1None
Suitable for safety functionsYes
Width12.5mm
Degree of protection (IP)IP20
Depth113.7mm
Galvanic separation between output to outputYes
Mounting methodOther
Power consumption0.8W
Construction type of deviceBuilt-in device
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924281 | MACX MCR-SL-2NAM-T-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Number of inputs, potential-free
2
Switching current
0.05A
Number of inputs, according to NAMUR
2
Number of output circuits transistor potential-free
1
Switching voltage
30V
Number of output circuits relays normally open contact
0
Number of output circuits relays change-over contact
0
Number of output circuits opto-coupler
0
Type of power supply
Other
Malfunction message output
Inherently safe according to EN 60947-5-6 NAMUR
Number of channels
2
Galvanic separation between inputs
Number of output circuits transistor pnp
1
Rated supply voltage at DC
19.2 .. 30V
Number of output circuits transistor antivalent
0
Number of output circuits transistor npn
0
Galvanic separation between input and output
Height
116mm
Type of electric connection
Other
Operating temperature
-40 .. 70°C
Galvanic separation between supply voltage and all other current circuits
Performance level according to EN ISO 13849-1
None
Suitable for safety functions
Width
12.5mm
Degree of protection (IP)
IP20
Depth
113.7mm
Galvanic separation between output to output
Mounting method
Other
Power consumption
0.8W
Construction type of device
Built-in device
