Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of output circuits relays change-over contact0
Number of inputs, potential-free2
Number of output circuits transistor pnp0
Number of output circuits transistor npn0
Number of output circuits transistor antivalent0
Switching power500VA
Number of inputs, according to NAMUR2
Rated supply voltage at DC19.2 - 30V
Type of power supplyOther
Number of channels2
Galvanic separation between inputsNo
Switching voltage250V
Number of output circuits transistor potential-free0
Number of output circuits relays normally open contact2
Malfunction message outputNo
Number of output circuits opto-coupler0
Galvanic separation between input and outputYes
Inherently safe according to EN 60947-5-6 NAMURNo
Mounting methodOther
Width12.5mm
Galvanic separation between output to outputYes
Type of electric connectionOther
Construction type of deviceBuilt-in device
Power consumption1W
Height107.9mm
Operating temperature-40 - 60°C
Performance level according to EN ISO 13849-1None
Suitable for safety functionsYes
Galvanic separation between supply voltage and all other current circuitsYes
Degree of protection (IP)IP20
Depth113.7mm
