Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of inputs, potential-free2
Rated supply voltage at AC19.2 - 253V
Rated supply voltage at DC19.2 - 253V
Switching voltage250V
Number of inputs, according to NAMUR2
Number of output circuits relays normally open contact2
Number of channels2
Type of power supplyOther
Number of output circuits transistor npn0
Switching power500VA
Number of output circuits transistor potential-free0
Number of output circuits transistor pnp0
Number of output circuits opto-coupler0
Number of output circuits transistor antivalent0
Malfunction message outputNo
Inherently safe according to EN 60947-5-6 NAMURNo
Number of output circuits relays change-over contact2
Galvanic separation between inputsNo
Galvanic separation between output to outputYes
Galvanic separation between supply voltage and all other current circuitsYes
Width17.5mm
Type of electric connectionOther
Performance level according to EN ISO 13849-1None
Operating temperature-40 - 60°C
Suitable for safety functionsYes
Height107.9mm
Galvanic separation between input and outputYes
Power consumption1.1W
Construction type of deviceBuilt-in device
Mounting methodOther
Depth113.7mm
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2924304 | MACX MCR-SL-2NAM-R-UP-SP
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- NAMUR switching amplifier
- 1 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Number of inputs, potential-free
2
Rated supply voltage at AC
19.2 .. 253V
Rated supply voltage at DC
19.2 .. 253V
Switching voltage
250V
Number of inputs, according to NAMUR
2
Number of output circuits relays normally open contact
2
Number of channels
2
Type of power supply
Other
Number of output circuits transistor npn
0
Switching power
500VA
Number of output circuits transistor potential-free
0
Number of output circuits transistor pnp
0
Number of output circuits opto-coupler
0
Number of output circuits transistor antivalent
0
Malfunction message output
Inherently safe according to EN 60947-5-6 NAMUR
Number of output circuits relays change-over contact
2
Galvanic separation between inputs
Galvanic separation between output to output
Galvanic separation between supply voltage and all other current circuits
Width
17.5mm
Type of electric connection
Other
Performance level according to EN ISO 13849-1
None
Operating temperature
-40 .. 60°C
Suitable for safety functions
Height
107.9mm
Galvanic separation between input and output
Power consumption
1.1W
Construction type of device
Built-in device
Mounting method
Other
Depth
113.7mm
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
