Details
- •Sensors
- •NAMUR switching amplifier
- •1 KOM
- •PHOENIX
Technical specifications
Number of output circuits relays normally open contact0
Number of channels1
Number of inputs, potential-free1
Number of inputs, according to NAMUR1
Rated supply voltage at DC9.6 - 30V
Number of output circuits transistor npn0
Number of output circuits transistor potential-free1
Number of output circuits relays change-over contact0
Number of output circuits transistor antivalent0
Malfunction message outputNo
Type of power supplyOther
Number of output circuits transistor pnp1
Galvanic separation between output to outputNo
Galvanic separation between inputsNo
Galvanic separation between input and outputYes
Number of output circuits opto-coupler0
Inherently safe according to EN 60947-5-6 NAMURYes
Switching voltage8.2V
Suitable for safety functionsYes
Galvanic separation between supply voltage and all other current circuitsYes
Height116mm
Width12.5mm
Performance level according to EN ISO 13849-1None
Power consumption0.6W
Operating temperature-40 - 70°C
Construction type of deviceBuilt-in device
Type of electric connectionOther
Mounting methodOther
Degree of protection (IP)IP20
Depth113.7mm
