Details
- •Terminal blocks
- •Component terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Connectable conductor cross section solid-core0.08 - 4mm²
Type of electrical connection 1Spring clamp connection
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 0.14mm²
Rated current In0.5A
Connectable conductor cross section fine-strand without cable end sleeve0.08 - 2.5mm²
Rated voltage250V
Type of electrical connection 2Spring clamp connection
Number of clamp positions per level2
Mounting methodDIN rail (top hat rail) 35 mm
Number of levels2
Inflammability class of insulation material according to with UL94V0
Material insulation bodyOther
Height67.5mm
Internally connected stagesNo
Width5.2mm
Depth47.5mm
Closing plate requiredYes
ColourGrey
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
3031584 | STTB 2,5-2DIO/O-UL/UR-UL
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Terminal blocks
- Component terminal block
- 50 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Connectable conductor cross section solid-core
0.08 .. 4mm²
Type of electrical connection 1
Spring clamp connection
Connectable conductor cross section fine-strand with cable end sleeve
0.14 .. 0.14mm²
Rated current In
0.5A
Connectable conductor cross section fine-strand without cable end sleeve
0.08 .. 2.5mm²
Rated voltage
250V
Type of electrical connection 2
Spring clamp connection
Number of clamp positions per level
2
Mounting method
DIN rail (top hat rail) 35 mm
Number of levels
2
Inflammability class of insulation material according to with UL94
V0
Material insulation body
Other
Height
67.5mm
Internally connected stages
Width
5.2mm
Depth
47.5mm
Closing plate required
Colour
Grey
Related products
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
