Details
- •Terminal blocks
- •(Knife) disconnect terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Type of electrical connection 2Screw connection
Connectable conductor cross section fine-strand without cable end sleeve0.14 - 4mm²
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 0.14mm²
Connectable conductor cross section multi-wired0.14 - 1.5mm²
Connectable conductor cross section solid-core0.14 - 4mm²
Number of clamp positions per level2
Rated current In20A
Rated voltage400V
Internally connected stagesYes
Material insulation bodyOther
Mounting methodDIN rail (top hat rail) 35 mm
Width5.2mm
Inflammability class of insulation material according to with UL94V0
Type of electrical connection 1Screw connection
Depth49.1mm
Height57.8mm
Closing plate requiredYes
ColourBlue
Type of cross disconnectionNone
With integrated test socketNo
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
3046553 | UT 2,5-MT BU
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Terminal blocks
- (Knife) disconnect terminal block
- 50 KOM
- PHOENIX
DetailsTechnical specificationsRelated products
Technical specifications
Type of electrical connection 2
Screw connection
Connectable conductor cross section fine-strand without cable end sleeve
0.14 .. 4mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.14 .. 0.14mm²
Connectable conductor cross section multi-wired
0.14 .. 1.5mm²
Connectable conductor cross section solid-core
0.14 .. 4mm²
Number of clamp positions per level
2
Rated current In
20A
Rated voltage
400V
Internally connected stages
Material insulation body
Other
Mounting method
DIN rail (top hat rail) 35 mm
Width
5.2mm
Inflammability class of insulation material according to with UL94
V0
Type of electrical connection 1
Screw connection
Depth
49.1mm
Height
57.8mm
Closing plate required
Colour
Blue
Type of cross disconnection
None
With integrated test socket
