Details
- •Terminal blocks
- •Feed-through terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Connectable conductor cross section fine-strand without cable end sleeve0.14 - 4mm²
Suitable for conductor materialAluminium/copper
Type of electrical connection 2Other
Mounting methodDIN rail (top hat rail) 35 mm
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 0.14mm²
Operating temperature-60 - 110°C
Width5.2mm
Depth35.3mm
Material insulation bodyOther
Type of electrical connection 1Other
Inflammability class of insulation material according to with UL94V0
Closing plate requiredYes
Height72.2mm
Internally connected stagesYes
Number of levels1
Number of clamp positions per level4
ColourGrey
Rated voltage800V
Connectable conductor cross section solid-core0.14 - 4mm²
Rated current In24A
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
3209578 | PT 2,5-QUATTRO
