Details
- •Terminal blocks
- •Component terminal block
- •50 KOM
- •PHOENIX
Technical specifications
Connectable conductor cross section solid-core0.14 - 4mm²
Connectable conductor cross section fine-strand without cable end sleeve0.14 - 4mm²
Number of levels2
Internally connected stagesNo
Rated voltage500V
Number of clamp positions per level2
Height68mm
Type of electrical connection 2Other
Material insulation bodyOther
Width5.2mm
Depth47.5mm
Closing plate requiredYes
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 0.14mm²
Mounting methodDIN rail (top hat rail) 35 mm
Rated current In0.5A
Type of electrical connection 1Other
ColourGrey
Inflammability class of insulation material according to with UL94V0
