Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Supporting protocol for TCP/IPYes
With control elementYes
Number of analogue inputs3
Number of analogue outputs1
With optical interfaceNo
Number of digital outputs3
Number of HW-interfaces RS-4851
Number of HW-interfaces parallel0
Number of HW-interfaces RS-2320
Width320mm
Number of HW-interfaces serial TTY0
Depth300mm
Number of HW-interfaces RS-4220
Supporting protocol for LONNo
Number of HW-interfaces other1
Height521mm
Number of HW-interfaces USB0
Number of digital inputs7
Number of HW-interfaces industrial Ethernet0
Supporting protocol for CANYes
Supporting protocol for SUCONETNo
With PC connectionYes
Number of phases input3
Supporting protocol for Data-HighwayNo
Degree of protection (IP)IP66
Supporting protocol for ASINo
Supporting protocol for SERCOSNo
Type of converterU converter
Supporting protocol for INTERBUSNo
4-quadrant operation possibleYes
Supporting protocol for other bus systemsYes
Number of phases output3
Application in industrial area permittedYes
Supporting protocol for ModbusYes
Supporting protocol for DeviceNetYes
Supporting protocol for PROFIBUSYes
Number of interfaces PROFINET0
Mains voltage380 - 500V
Supporting protocol for INTERBUS-SafetyNo
Mains frequency50/60 Hz
Integrated breaking resistanceYes
Supporting protocol for KNXNo
Max. output frequency599Hz
Application in domestic- and commercial area permittedNo
Max. output at quadratic load at rated output voltage5.5kW
Max. output at linear load at rated output voltage5.5kW
Supporting protocol for DeviceNet SafetyNo
Relative symmetric net voltage tolerance10%
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET CBANo
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net frequency tolerance5%
Supporting protocol for PROFINET IOYes
Supporting protocol for EtherNet/IPYes
Supporting protocol for SafetyBUS pNo
Max. output voltage500V
Nominal output current I2N14.3A
Supporting protocol for Foundation FieldbusNo
Supporting protocol for BACnetNo
Degree of protection (NEMA)4X
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV320U55N4W | Frek. Pret. ATV320 5,5KW 400V 3PH IP66
