Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •1 KOM
- •SCHNEIDER
Technical specifications
Depth300mm
Height521mm
With control elementYes
Width320mm
Number of analogue inputs3
Number of digital outputs3
Number of digital inputs7
Number of HW-interfaces other1
Supporting protocol for LONNo
With optical interfaceNo
Number of HW-interfaces USB0
Number of HW-interfaces serial TTY0
Number of HW-interfaces industrial Ethernet0
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-4851
Number of analogue outputs1
Number of HW-interfaces parallel0
Number of HW-interfaces RS-2320
Supporting protocol for INTERBUSNo
Supporting protocol for other bus systemsYes
Supporting protocol for CANYes
Supporting protocol for Data-HighwayNo
Supporting protocol for ASINo
Supporting protocol for DeviceNetYes
Supporting protocol for SUCONETNo
Supporting protocol for ModbusYes
Supporting protocol for TCP/IPYes
Supporting protocol for KNXNo
Supporting protocol for PROFIBUSYes
Mains voltage380 - 500V
4-quadrant operation possibleYes
Supporting protocol for INTERBUS-SafetyNo
Number of interfaces PROFINET0
Mains frequency50/60 Hz
Supporting protocol for SERCOSNo
Type of converterU converter
With PC connectionYes
Degree of protection (IP)IP65
Application in industrial area permittedYes
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPYes
Number of phases input3
Number of phases output3
Supporting protocol for DeviceNet SafetyNo
Application in domestic- and commercial area permittedNo
Supporting protocol for PROFINET IOYes
Supporting protocol for Foundation FieldbusNo
Max. output at linear load at rated output voltage7.5kW
Integrated breaking resistanceYes
Relative symmetric net frequency tolerance5%
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net voltage tolerance10%
Max. output frequency599Hz
Max. output at quadratic load at rated output voltage7.5kW
Supporting protocol for SafetyBUS pNo
Degree of protection (NEMA)12
Supporting protocol for PROFIsafeNo
Max. output voltage500V
Nominal output current I2N17A
Supporting protocol for BACnetNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
ATV320U75N4WS | Frek. Pret. ATV320 7,5KW 400V 3PH Vario
