Details

  • •Low-voltage industrial components
  • •Frequency converter =< 1 kV
  • •Minimum order quantity: 1 pcs
  • •SCHNEIDER

Technical specifications

Height630mm
Number of HW-interfaces industrial Ethernet0
Number of analogue inputs3
Number of analogue outputs2
With control elementNo
Width331mm
Number of digital outputs0
Number of digital inputs6
Supporting protocol for LONNo
Depth297mm
Number of HW-interfaces serial TTY0
Number of HW-interfaces USB0
Number of HW-interfaces RS-4220
Number of HW-interfaces parallel0
Number of HW-interfaces RS-4852
Supporting protocol for ASINo
Number of HW-interfaces other0
Number of HW-interfaces RS-2320
With optical interfaceYes
Supporting protocol for PROFIBUSYes
Supporting protocol for TCP/IPYes
Supporting protocol for INTERBUSNo
Supporting protocol for CANYes
Supporting protocol for KNXNo
Supporting protocol for ModbusYes
Supporting protocol for SERCOSNo
Supporting protocol for other bus systemsNo
Mains frequency50/60 Hz
With PC connectionNo
Supporting protocol for Data-HighwayNo
Supporting protocol for SUCONETNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for DeviceNetYes
Number of interfaces PROFINET0
Max. output at quadratic load at rated output voltage75kW
Relative symmetric net voltage tolerance10%
Relative symmetric net frequency tolerance5%
Integrated breaking resistanceNo
Supporting protocol for AS-Interface Safety at WorkNo
Max. output frequency500Hz
Application in industrial area permittedNo
Application in domestic- and commercial area permittedNo
Type of converterU converter
4-quadrant operation possibleNo
Supporting protocol for DeviceNet SafetyNo
Max. output voltage690V
Supporting protocol for EtherNet/IPYes
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET CBANo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET IONo
Supporting protocol for BACnetNo
Degree of protection (IP)IP00
Mains voltage500 - 690V
Number of phases output2
Number of phases input3
Max. output at linear load at rated output voltage75kW
Nominal output current I2N83A
