ATV930D90Y6 | Frek. Pret. IP00 90KW 500V/690V
Code: 1852615
ManufacturerSchneider Electric
Catalog numberATV930D90Y6
TypeATV930D90Y6
CategoryFrequency converter =< 1 kV
EAN code3606481325389
Details
- •Low-voltage industrial components
- •Frequency converter =< 1 kV
- •Minimum order quantity: 1 pcs
- •SCHNEIDER
Technical specifications
Number of digital inputs8
Width331mm
Depth297mm
With control elementYes
Number of digital outputs1
Height630mm
Number of HW-interfaces RS-4220
Number of HW-interfaces USB0
Supporting protocol for LONNo
Number of analogue outputs2
Number of HW-interfaces industrial Ethernet2
Number of HW-interfaces serial TTY0
Number of HW-interfaces parallel0
Number of HW-interfaces RS-2320
Number of analogue inputs3
Number of HW-interfaces other0
Supporting protocol for PROFIBUSYes
With optical interfaceYes
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusYes
Supporting protocol for CANNo
Supporting protocol for KNXNo
Supporting protocol for ASINo
Supporting protocol for TCP/IPYes
Supporting protocol for Data-HighwayNo
With PC connectionNo
Supporting protocol for other bus systemsNo
Supporting protocol for SUCONETNo
Supporting protocol for DeviceNetYes
Number of HW-interfaces RS-4852
Number of interfaces PROFINET0
Mains frequency50/60 Hz
Supporting protocol for INTERBUS-SafetyNo
Type of converterU converter
4-quadrant operation possibleNo
Integrated breaking resistanceNo
Max. output at quadratic load at rated output voltage90kW
Max. output frequency30000Hz
Application in industrial area permittedNo
Supporting protocol for SERCOSNo
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for AS-Interface Safety at WorkNo
Relative symmetric net voltage tolerance10%
Relative symmetric net frequency tolerance5%
Application in domestic- and commercial area permittedNo
Supporting protocol for Foundation FieldbusNo
Supporting protocol for PROFIsafeNo
Supporting protocol for PROFINET CBANo
Supporting protocol for EtherNet/IPYes
Supporting protocol for PROFINET IONo
Supporting protocol for SafetyBUS pNo
Max. output voltage30V
Supporting protocol for BACnetNo
Degree of protection (IP)IP00
Mains voltage500 - 690V
Number of phases output2
Number of phases input3
Max. output at linear load at rated output voltage90kW
Nominal output current I2N108A
