Details
- •Low-voltage industrial components
- •Fuse switch disconnector
- •1 KOM
- •ABB
Technical specifications
Degree of protection (IP), front sideIP30
Cable entryFloor (bottom)
Number of poles3
Suitable for fusesNH1
Conditioned rated short-circuit current Iq100kA
Rated permanent current Iu250A
Motor drive integratedNo
Type of electrical connection of main circuitCable clamp
Suitable for front mountingNo
Version as main switchNo
Suitable for busbar mountingYes
Type of control elementOther
Rated short-time withstand current lcw-kA
Rated operation power at AC-23, 400 V-kW
Suitable for floor mountingNo
Max. rated operation voltage Ue AC690V
With error protectionNo
Version as safety switchNo
Version as emergency stop installationNo
Position control elementFront side
Equipped with connectorsNo
Motor drive optionalNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SEP620011R3121 | ZLBM1-3P-Z-V-EFM
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Degree of protection (IP), front side
IP30
Cable entry
Floor (bottom)
Number of poles
3
Suitable for fuses
NH1
Conditioned rated short-circuit current Iq
100kA
Rated permanent current Iu
250A
Motor drive integrated
Type of electrical connection of main circuit
Cable clamp
Suitable for front mounting
Version as main switch
Suitable for busbar mounting
Type of control element
Other
Rated short-time withstand current lcw
-kA
Rated operation power at AC-23, 400 V
-kW
Suitable for floor mounting
Max. rated operation voltage Ue AC
690V
With error protection
Version as safety switch
Version as emergency stop installation
Position control element
Front side
Equipped with connectors
Motor drive optional
