Details
- •Installation bus systems
- •Switch actuator for bus system
- •1 KOM
- •ABB
Technical specifications
Mounting methodDRA (DIN-rail adapter)
Rated operating voltage230 - 230V
Bus system radio frequentNo
Output power2500W
Width in number of modular spacings2
Max. switching power2500W
With bus connectionYes
Different phases connectableYes
Min. depth of built-in installation box64.5mm
Bus system KNX radioNo
Other bus systemsNone
With LED indicationYes
Rated current16A
Suitable for C-loadNo
Bus system KNXYes
Radio frequent bidirectionalNo
Number of digital inputs0
Local operation/hand operationYes
Degree of protection (IP)IP20
Modular expandabilityYes
Max. switching current16A
Bus module detachableYes
Bus system LONNo
Bus system PowernetNo
Max. number of switching contacts2
Max. switching power LED400W
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
2CDG110261R0011 | SA/S2.16.2.2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Installation bus systems
- Switch actuator for bus system
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Mounting method
DRA (DIN-rail adapter)
Rated operating voltage
230 .. 230V
Bus system radio frequent
Output power
2500W
Width in number of modular spacings
2
Max. switching power
2500W
With bus connection
Different phases connectable
Min. depth of built-in installation box
64.5mm
Bus system KNX radio
Other bus systems
None
With LED indication
Rated current
16A
Suitable for C-load
Bus system KNX
Radio frequent bidirectional
Number of digital inputs
0
Local operation/hand operation
Degree of protection (IP)
IP20
Modular expandability
Max. switching current
16A
Bus module detachable
Bus system LON
Bus system Powernet
Max. number of switching contacts
2
Max. switching power LED
400W
