Details
- •Low-voltage industrial components
- •Switch disconnector
- •1 KOM
- •LEGRAND
Technical specifications
Rated permanent current Iu63A
Number of auxiliary contacts as normally closed contact0
Rated operation power at AC-3, 400 V18.5kW
Number of auxiliary contacts as normally open contact0
Version as emergency stop installationNo
Degree of protection (IP), front sideIP40
Motor drive integratedNo
Number of poles3
Number of switches-
Type of electrical connection of main circuitScrew connection
Rated operating voltage690 - 690V
Conditioned rated short-circuit current Iq10kA
Number of auxiliary contacts as change-over contact0
InterlockableNo
Version as safety switchNo
Suitable for floor mountingYes
Rated operation power at AC-23, 400 V22kW
Suitable for front mounting 4-holeYes
Rated short-time withstand current lcw1.8kA
Suitable for front mounting centreYes
Suitable for distribution board installationNo
Version as maintenance-/service switchNo
Version as main switchNo
Max. rated operation voltage Ue AC690V
Motor drive optionalNo
Suitable for intermediate mountingNo
Version as reversing switchNo
Voltage release optionalNo
Rated permanent current at AC-21, 400 V63A
Switching power at 400 V25.2kW
Rated permanent current at AC-23, 400 V-A
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
022150 | RASTAVNA SKLOPKA 63A
