Details
- •Low-voltage industrial components
- •Power contactor, AC switching
- •1 KOM
- •EATON
Technical specifications
Rated operation power at AC-3, 400 V250kW
Rated operation current Ie at AC-1, 400 V800A
Number of auxiliary contacts as normally closed contact2
Width160mm
Rated control supply voltage Us at DC0 - 0V
Height219mm
Depth216mm
Number of normally closed contacts as main contact0
Rated operation current Ie at AC-3, 400 V500A
Modular versionNo
Number of normally open contacts as main contact3
Rated control supply voltage Us at AC 60HZ220 - 240V
Type of electrical connection of main circuitRail connection
Rated control supply voltage Us at AC 50HZ220 - 240V
Number of auxiliary contacts as normally open contact2
Operating voltage at AC 60 Hz220 - 240V
Rated operation current Ie at AC-4, 400 V360A
Operating voltage at AC 50 Hz220 - 240V
Voltage type for actuatingAC
Rated operation power at AC-4, 400 V200kW
Rated operation power NEMA298kW
Related products
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
DILM500-S/22(220-240V50/60HZ)
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Power contactor, AC switching
- 1 KOM
- EATON
DetailsTechnical specificationsRelated products
Technical specifications
Rated operation power at AC-3, 400 V
250kW
Rated operation current Ie at AC-1, 400 V
800A
Number of auxiliary contacts as normally closed contact
2
Width
160mm
Rated control supply voltage Us at DC
0 .. 0V
Height
219mm
Depth
216mm
Number of normally closed contacts as main contact
0
Rated operation current Ie at AC-3, 400 V
500A
Modular version
Number of normally open contacts as main contact
3
Rated control supply voltage Us at AC 60HZ
220 .. 240V
Type of electrical connection of main circuit
Rail connection
Rated control supply voltage Us at AC 50HZ
220 .. 240V
Number of auxiliary contacts as normally open contact
2
Operating voltage at AC 60 Hz
220 .. 240V
Rated operation current Ie at AC-4, 400 V
360A
Operating voltage at AC 50 Hz
220 .. 240V
Voltage type for actuating
AC
Rated operation power at AC-4, 400 V
200kW
Rated operation power NEMA
298kW
