Details
- •Programmable logic controllers PLC
- •Logic module
- •1 KOM
- •EATON
Technical specifications
Height90mm
Width72mm
Depth58mm
With time switch clockYes
Number of HW-interfaces RS-2320
Voltage type of supply voltageDC
Supporting protocol for TCP/IPYes
Number of HW-interfaces industrial Ethernet1
Number of HW-interfaces RS-4220
Supporting protocol for ASINo
Supporting protocol for LONNo
Switching current0.5A
Number of HW-interfaces parallel0
Supporting protocol for CANNo
ExpandableYes
Suitable for safety functionsNo
Number of analogue inputs0
With optical interfaceNo
Number of HW-interfaces RS-4850
Number of HW-interfaces USB0
Number of HW-interfaces serial TTY0
Supporting protocol for PROFIBUSNo
Power consumption2W
Number of HW-interfaces other0
Number of digital inputs8
With displayYes
Number of digital outputs4
Number of analogue outputs0
Rail mounting possibleYes
Number of interfaces PROFINET0
Number of HW-interfaces Wireless0
Explosion safety category for gasNone
Supporting protocol for INTERBUS-SafetyNo
Degree of protection (IP)IP20
Rack-assembly possibleNo
Wall mounting/direct mountingYes
Supporting protocol for SERCOSNo
With relay outputNo
Radio standard Wi-Fi 802.11No
Supporting protocol for other bus systemsNo
Appendant operation agent (Ex ia)No
Radio standard BluetoothNo
Supporting protocol for INTERBUSNo
Appendant operation agent (Ex ib)No
Supporting protocol for DeviceNetNo
Supporting protocol for ModbusYes
Supporting protocol for SUCONETNo
Supporting protocol for KNXNo
Expansion deviceNo
Supporting protocol for Data-HighwayNo
RedundancyNo
Front built-in possibleYes
Explosion safety category for dustNone
Basic deviceYes
Supporting protocol for PROFINET IONo
Radio standard UMTSNo
Certified for UL hazardous location class IIINo
Certified for UL hazardous location class IINo
Certified for UL hazardous location class IYes
Radio standard GPRSNo
Supply voltage AC 50 Hz0 - 0V
IO link masterNo
Supporting protocol for SafetyBUS pNo
Supporting protocol for PROFINET CBANo
SIL according to IEC 61508None
Supporting protocol for EtherNet/IPNo
Certified for UL hazardous location division 1No
Supporting protocol for EtherCATNo
Supporting protocol for AS-Interface Safety at WorkNo
Performance level according to EN ISO 13849-1None
Supply voltage AC 60 Hz0 - 0V
Supporting protocol for PROFIsafeNo
Radio standard GSMNo
Supporting protocol for Foundation FieldbusNo
Supply voltage DC20.4 - 28.8V
Supporting protocol for DeviceNet SafetyNo
Certified for UL hazardous location group A (acetylene)Yes
Certified for UL hazardous location division 2Yes
Certified for UL hazardous location group C (ethylene)Yes
Certified for UL hazardous location group B (hydrogen)No
Certified for UL hazardous location group G (non-conductive dusts)No
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group D (propane)Yes
Certified for UL hazardous location group E (metal dusts)No
