Details
- •Programmable logic controllers PLC
- •Logic module
- •1 KOM
- •EATON
Technical specifications
Width72mm
Height90mm
Depth58mm
With time switch clockYes
Number of digital inputs8
Power consumption2W
Suitable for safety functionsNo
ExpandableYes
With displayNo
Switching current0.5A
Number of digital outputs4
Number of analogue inputs0
Number of HW-interfaces RS-4220
Number of HW-interfaces RS-2320
Number of HW-interfaces parallel0
Number of HW-interfaces other0
Number of HW-interfaces industrial Ethernet1
Supporting protocol for LONNo
Voltage type of supply voltageDC
Supporting protocol for TCP/IPYes
Number of analogue outputs0
Number of HW-interfaces RS-4850
Number of HW-interfaces USB0
Supporting protocol for PROFIBUSNo
With optical interfaceNo
Supporting protocol for ASINo
Number of HW-interfaces serial TTY0
Supporting protocol for INTERBUSNo
Supporting protocol for ModbusYes
Supporting protocol for Data-HighwayNo
Supporting protocol for other bus systemsNo
Supporting protocol for KNXNo
Supporting protocol for DeviceNetNo
Supporting protocol for SUCONETNo
Supporting protocol for CANNo
RedundancyNo
Supporting protocol for SERCOSNo
With relay outputNo
Appendant operation agent (Ex ib)No
Explosion safety category for dustNone
Explosion safety category for gasNone
Degree of protection (IP)IP20
Appendant operation agent (Ex ia)No
Rail mounting possibleYes
Number of interfaces PROFINET0
Supporting protocol for INTERBUS-SafetyNo
Number of HW-interfaces Wireless0
Supporting protocol for DeviceNet SafetyNo
Rack-assembly possibleNo
Radio standard BluetoothNo
Supporting protocol for EtherNet/IPNo
Basic deviceYes
Expansion deviceNo
Wall mounting/direct mountingYes
Front built-in possibleYes
Supporting protocol for Foundation FieldbusNo
Performance level according to EN ISO 13849-1None
Radio standard Wi-Fi 802.11No
IO link masterNo
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for PROFINET CBANo
Radio standard GPRSNo
Certified for UL hazardous location class IYes
SIL according to IEC 61508None
Supply voltage AC 60 Hz0 - 0V
Supporting protocol for PROFINET IONo
Radio standard GSMNo
Supply voltage AC 50 Hz0 - 0V
Radio standard UMTSNo
Supply voltage DC20.4 - 28.8V
Supporting protocol for EtherCATNo
Certified for UL hazardous location class IIINo
Supporting protocol for SafetyBUS pNo
Certified for UL hazardous location class IINo
Certified for UL hazardous location division 2Yes
Certified for UL hazardous location division 1No
Certified for UL hazardous location group D (propane)Yes
Certified for UL hazardous location group E (metal dusts)No
Certified for UL hazardous location group F (carbonaceous dusts)No
Certified for UL hazardous location group B (hydrogen)No
Certified for UL hazardous location group C (ethylene)Yes
Certified for UL hazardous location group A (acetylene)Yes
Supporting protocol for PROFIsafeNo
Certified for UL hazardous location group G (non-conductive dusts)No
