Details
- •Low-voltage industrial components
- •Motor starter/Motor starter combination
- •1 KOM
- •EATON
Technical specifications
With transformerNo
Depth114.5mm
Height99mm
Rated operation power at AC-3, 400 V1.1kW
Number of auxiliary contacts as normally open contact0
Width22.5mm
Number of command positions-
Number of auxiliary contacts as normally closed contact0
Rated operation current Ie3A
Suitable for emergency stopNo
Supporting protocol for LONNo
Overload release current setting0.18 - 3A
Supporting protocol for INTERBUSNo
Number of indicator lights5
External reset possibleNo
Supporting protocol for SUCONETNo
Supporting protocol for Data-HighwayNo
Supporting protocol for ASINo
Release classCLASS 10
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at DC24 - 24V
Degree of protection (IP)IP20
Rated control supply voltage Us at AC 50HZ0 - 0V
Supporting protocol for PROFIBUSNo
Supporting protocol for CANNo
Supporting protocol for TCP/IPNo
Rail mounting possibleYes
Supporting protocol for SERCOSNo
Supporting protocol for other bus systemsYes
Supporting protocol for DeviceNetNo
Supporting protocol for INTERBUS-SafetyNo
Supporting protocol for ModbusNo
With short-circuit releaseNo
With fuseNo
Type of electrical connection of main circuitSpring clamp connection
Supporting protocol for DeviceNet SafetyNo
Supporting protocol for PROFINET CBANo
Supporting protocol for PROFINET IONo
Supporting protocol for PROFIsafeNo
Type of electrical connection for auxiliary- and control current circuitSpring clamp connection
Supporting protocol for SafetyBUS pNo
Supporting protocol for EtherNet/IPNo
Voltage type for actuatingDC
Supporting protocol for AS-Interface Safety at WorkNo
Supporting protocol for Foundation FieldbusNo
Rated operation current at AC-3, 400 V3A
Rated operation power at AC-3, 230 V, 3-phase0.55kW
Ambient temperature, upper operating limit60°C
Rated conditional short-circuit current, type 2, 230 V0A
Type of motor starterReversing starter
Rated conditional short-circuit current, type 2, 400 V0A
Rated power, 575 V, 60 Hz, 3-phase0kW
Rated power, 460 V, 60 Hz, 3-phase0kW
Temperature compensated overload protectionYes
Rated conditional short-circuit current, type 1, 480 Y/277 V0A
Rated conditional short-circuit current, type 1, 600 Y/347 V0A
Degree of protection (NEMA)Other
