Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Voltage typeDC
CascadableNo
Material housingMetal
Switching distance2mm
Number of protected contact energized outputs0
Suitable for safety functionsNo
Number of semiconductor outputs with signalling function1
Number of protected semiconductor outputs0
Number of contact energized outputs with signalling function0
Switching frequency2000Hz
Type of electric connectionCable
Coating housingOther
Type of interface for safety communicationNone
Type of switch functionBreaker contact
Max. output current at protected output0mA
Mechanical mounting condition for sensorConcise
Type of interfaceNone
With monitoring function downstream switching devicesNo
Category according to EN 954-1B
Rated control supply voltage Us at DC10 - 30V
Type of switching outputNPN
Explosion safety category for dustNone
Construction type housingCylinder, screw-thread
Rated control supply voltage Us at AC 60HZ0 - 0V
Explosion safety category for gasNone
Rated control supply voltage Us at AC 50HZ0 - 0V
Supply voltage10 - 30V
Type of actuationMetallic Target
Diameter sensor12mm
Performance level according to EN ISO 13849-1None
Compression-resistantNo
SIL according to IEC 61508None
Width sensor0mm
Length of sensor64.1mm
Height of sensor0mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E57P-12SNC2-C2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Voltage type
DC
Cascadable
Material housing
Metal
Switching distance
2mm
Number of protected contact energized outputs
0
Suitable for safety functions
Number of semiconductor outputs with signalling function
1
Number of protected semiconductor outputs
0
Number of contact energized outputs with signalling function
0
Switching frequency
2000Hz
Type of electric connection
Cable
Coating housing
Other
Type of interface for safety communication
None
Type of switch function
Breaker contact
Max. output current at protected output
0mA
Mechanical mounting condition for sensor
Concise
Type of interface
None
With monitoring function downstream switching devices
Category according to EN 954-1
B
Rated control supply voltage Us at DC
10 .. 30V
Type of switching output
NPN
Explosion safety category for dust
None
Construction type housing
Cylinder, screw-thread
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Explosion safety category for gas
None
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Supply voltage
10 .. 30V
Type of actuation
Metallic Target
Diameter sensor
12mm
Performance level according to EN ISO 13849-1
None
Compression-resistant
SIL according to IEC 61508
None
Width sensor
0mm
Length of sensor
64.1mm
Height of sensor
0mm
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
