Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Switching frequency2000Hz
Voltage typeDC
Material housingMetal
Suitable for safety functionsNo
CascadableNo
Coating housingOther
Number of protected semiconductor outputs0
Switching distance4mm
Number of semiconductor outputs with signalling function1
Type of interface for safety communicationNone
Number of contact energized outputs with signalling function0
Number of protected contact energized outputs0
Type of switching outputNPN
Type of switch functionBreaker contact
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at DC10 - 30V
Rated control supply voltage Us at AC 50HZ0 - 0V
Compression-resistantNo
Diameter sensor12mm
Category according to EN 954-1B
Height of sensor0mm
Width sensor0mm
Length of sensor64.1mm
Type of actuationMetallic Target
Construction type housingCylinder, screw-thread
Explosion safety category for gasNone
Type of interfaceNone
Type of electric connectionCable
Mechanical mounting condition for sensorNot flat
Supply voltage10 - 30V
With monitoring function downstream switching devicesNo
Explosion safety category for dustNone
Max. output current at protected output0mA
Performance level according to EN ISO 13849-1None
SIL according to IEC 61508None
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E57P-12UNC4-C2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Switching frequency
2000Hz
Voltage type
DC
Material housing
Metal
Suitable for safety functions
Cascadable
Coating housing
Other
Number of protected semiconductor outputs
0
Switching distance
4mm
Number of semiconductor outputs with signalling function
1
Type of interface for safety communication
None
Number of contact energized outputs with signalling function
0
Number of protected contact energized outputs
0
Type of switching output
NPN
Type of switch function
Breaker contact
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Rated control supply voltage Us at DC
10 .. 30V
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Compression-resistant
Diameter sensor
12mm
Category according to EN 954-1
B
Height of sensor
0mm
Width sensor
0mm
Length of sensor
64.1mm
Type of actuation
Metallic Target
Construction type housing
Cylinder, screw-thread
Explosion safety category for gas
None
Type of interface
None
Type of electric connection
Cable
Mechanical mounting condition for sensor
Not flat
Supply voltage
10 .. 30V
With monitoring function downstream switching devices
Explosion safety category for dust
None
Max. output current at protected output
0mA
Performance level according to EN ISO 13849-1
None
SIL according to IEC 61508
None
