Details
- •Sensors
- •Inductive proximity switch
- •1 KOM
- •EATON
Technical specifications
Suitable for safety functionsNo
CascadableNo
Material housingMetal
Voltage typeDC
Coating housingOther
Compression-resistantNo
Number of contact energized outputs with signalling function0
Number of semiconductor outputs with signalling function1
Switching distance22mm
Number of protected semiconductor outputs0
Rated control supply voltage Us at AC 50HZ0 - 0V
Type of interfaceNone
Supply voltage10 - 30V
With monitoring function downstream switching devicesNo
Category according to EN 954-1B
Number of protected contact energized outputs0
Mechanical mounting condition for sensorNot flat
Type of switching outputPNP
Width sensor0mm
Rated control supply voltage Us at AC 60HZ0 - 0V
Rated control supply voltage Us at DC10 - 30V
Explosion safety category for gasNone
Max. output current at protected output0mA
Type of interface for safety communicationNone
Switching frequency600Hz
Construction type housingCylinder, screw-thread
Type of electric connectionCable
Explosion safety category for dustNone
Type of switch functionBreaker contact
Type of actuationMetallic Target
Performance level according to EN ISO 13849-1None
Length of sensor67.7mm
Height of sensor0mm
Diameter sensor30mm
SIL according to IEC 61508None
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
E57G-30UPC22-C2
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Sensors
- Inductive proximity switch
- 1 KOM
- EATON
DetailsTechnical specifications
Technical specifications
Suitable for safety functions
Cascadable
Material housing
Metal
Voltage type
DC
Coating housing
Other
Compression-resistant
Number of contact energized outputs with signalling function
0
Number of semiconductor outputs with signalling function
1
Switching distance
22mm
Number of protected semiconductor outputs
0
Rated control supply voltage Us at AC 50HZ
0 .. 0V
Type of interface
None
Supply voltage
10 .. 30V
With monitoring function downstream switching devices
Category according to EN 954-1
B
Number of protected contact energized outputs
0
Mechanical mounting condition for sensor
Not flat
Type of switching output
PNP
Width sensor
0mm
Rated control supply voltage Us at AC 60HZ
0 .. 0V
Rated control supply voltage Us at DC
10 .. 30V
Explosion safety category for gas
None
Max. output current at protected output
0mA
Type of interface for safety communication
None
Switching frequency
600Hz
Construction type housing
Cylinder, screw-thread
Type of electric connection
Cable
Explosion safety category for dust
None
Type of switch function
Breaker contact
Type of actuation
Metallic Target
Performance level according to EN ISO 13849-1
None
Length of sensor
67.7mm
Height of sensor
0mm
Diameter sensor
30mm
SIL according to IEC 61508
None
VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
